The Triangles

DOUBLE-SIDED LEDs TRIANGLE

Regulatory signaling device for all vehicules and machines which are placed on the road during work or mobile road intervention.
•    Two dimensions : 500 or 700 mm.
•    Anodized aluminium box.
•    Mounting on double-acting hinge, for a forward or backward tilt of the box.
•    The lighting elements are made of three 70mm LEDs optics on both sides.
•    Dual voltage without bulb change (12 or 24 V).
• Supplied with 10m power cord.

TRIANGLE LED 500 - CLASS 2
Ref : 1566
The anodized aluminum casing is made up of two AK5 500 mm class 2 panels assembled back to back.It is mounted on a double-acting hinge which allows the triangle to tilt forwards or backwards.It is supplied with a 10 meter power cable.The triangle is made up of three extra flat Ø 72 ...
triangle-vehicule-tts-1566-triangle500-classe2

TRIANGLE LED 700 - CLASS 2
Ref : 1567
The anodized aluminum box is made up of two 700 mm class 2 AK5 panels assembled back to back.It is mounted on a double-acting hinge which allows the triangle to tilt forwards or backwards.It is supplied with a 10 meter power cable.The luminous element is composed of three extra flat...
triangle-vehicule-tts-1567-triangle700-classe2

MANUAL KIT
Ref : 1576
kit_de-rabattement_manuel

SINGLE-SIDED LEDs TRIANGLE

SINGLE-SIDED LEDs TRIANGLE 500
Ref : 1570
With rails fixed on the back The anodized aluminum casing is made up of two assembled 500mm sheets.On the front face is glued an AK5 class 2 adhesive and three optics are wired.Rear fixing by double rails.It is supplied with a 10 meter power cable.The triangle is made up of three extra flat Ø 72 mm opti...
triangle-simple-face-500-classe2-ref1570_04-05-2020_01-02-2022

SINGLE-SIDED LEDs TRIANGLE 700 - class1
Ref : 1571
With rails fixed on the back
triangle-simple-face-700-classe2-ref22928_01-02-2022

SINGLE-SIDED LEDs TRIANGLE 700 - class2
Ref : 22928
The anodized aluminum box is made up of two 700mm sheets assembled back to back.On the front face is glued an adhesive AK5 in class 2 and three optics.Rear fixing by double rails.It is supplied with a 10 meter power cable.The luminous element is composed of three extra flat opti...
triangle-simple-face-700-classe2-ref22928_01-02-2022
